Product Description
Model | WS-A1560 | WS-A2060 |
Working area | 1500x6000mm or 2000x6000mm | |
Spindle power | 9.0kw HSD Air-cooling | 9.0kw HSD Air-cooling |
Spindle speed | 24000rpm/min | |
Inverter | 11.0kw Delta | 11.0kw Delta |
Driving system | Japan YASKAWA Servo motor and drivers Japan Shimpo Reducer | |
Transmission | Taiwan Hiwin Square linear guide rails with X Y axis TBI Ball screw with Z axis | |
Operation system | Taiwan Syntec control system | |
Dust collector | 3.0kw with double bags | |
Oil lubrication | Automatic | |
Software compatibility | Artcam,Ucancam,JDpaint,etc | |
Working platform | Vacuum with pump | |
Gantry | Heavy cast steel | |
Lathe bed | Thicken steel tube | |
Electronic parts | Schneider | |
Relocating accuracy | ±0.05 mm | |
Max Moving speed | 80000mm/min | |
Max Working speed | 45000mm/min | |
Working voltage | 380/220V 3PH 50/60Hz | |
2060 ATC CNC Router Machine details and features:
| ◀ Italy HSD Air Cooling Spindle Top brand of the world. Spindle speed: 0-24000RPM. |
Japan Yaskawa servo motor ▶ Ensure high working efficiency and stable running ability Equipped with Japan Shimpo Reducer |
|
| ◀Taiwan Syntec Controller Advanced, Functional and Easy operation |
Automatic Tools Magazine ▶ It will change cutter tools automatically, fast chaning speed, improve working efficiency, save working time. Two roller bars keep the materials flat▶ |
|
 | ◀Vacuum table supplys suction to hold the material. Connect with China water-circulating pump or Germany Becker Pump ◀Locating pop-up pins can locate the materials in a very short time. |
Electrical control cabinet ▶ All the electrical parts connection is strictly comply with international standard, each line is marked with sign. Scheneider electrial parts▶ |  |
What materials can be processed by this atc cnc router machine?
Wood | √ |
ACP (aluminum composite panel) | √ |
ACM | √ |
Gypsum | √ |
Acrylic | √ |
Plastic | √ |
Aluminum | √ |
Engraving | √ |
Cutting | √ |
Drilling | √ |
Milling | √ |
Grooving | √ |
3D relief | √ |
Sawing | Optional |
Welcome to contact with us now to get detailed specifications, special discount and free accessories.
Packing and Delivery
Rather careful and professional packing way for machine protection.
1. Film. Put PE film on the machine and some spare parts, then put bubble wrap to the machine.
2. Free-fumigation wooden case with steel tube support on wooden cover. Humidity-proof paper above the wooden plate.
This kind of package could protect the machine very well from dust and humidity etc.
This 2060 ATC cnc router will be loading by 20ft container.
