Product Description
1).Powerful, short pulses, fast moving laser pulses act on the surface of the target, producing tiny plasma ruptures, shock waves, thermal stress, etc., causing surface materials to sublimate and evaporate.
2).The focused laser beam is capable of accurately evaporating surface objects or dirt.
3).Laser cleaning is suitable for metal surfaces. The treated and optimized laser beam does not alter metal properties or damage those laser treated surfaces. The precisely tuned laser beam acts only on the coating, residual residue or oxide, and does not harm the underlying parent metal surface.
4).By adjusting other parameters, the laser beam is able to achieve the desired cleaning effect accurately and easily.
Equipment model | WS-C50 | WS-C100 | WS-C200 | WS-C500 | WS-C1000 |
Laser working medium | Yb-doped fiber | ||||
Laser power | 50W | 100W | 200W | 500W | 1000W |
Laser wavelength | 1064nm | ||||
Pulse frequency | 20-100KHz | 20-100KHz | 20-200KHz | 20-50KHz | 20-50KHz |
Cooling method | Air cooling | Air cooling | Water cooling | Water cooling | Water cooling |
Dimension | 760mmX780X790mm | 1100x950x700mm | |||
Total Weight | 56kg | 60kg | 65kg | 130kg(Including Water tank) | 140kg |
Total power | 350W | 600W | 1000W | 1800W | 2000W |
| Working temperature | 5-40℃ | ||||
