WS-1610
1600X1000mm
Stepper
Ruida
Blade or Honeycomb
Product Description
WS-1610 Plywood Acrylic MDF Laser Cutting Machine 150w
Plywood Acrylic MDF Laser Cutting Machine 150w Technical specifications:
| Machine model: | WS-1610 Plywood Acrylic MDF Laser Cutting Machine |
| Working area | 1600*1000mm |
| laser type | Sealed CO2 glass laser tube, wavelength 10.6um |
| laser power | 60W/80W/100W/130W/150W |
| Cooling mode | Pure circulating water cooling |
| Control system | DSP offline control system, laser power software 0-100% adjustable |
| Max. engraving speed | 0-60000mm/min |
| Max cutting speed | 0-30000mm/min |
| Repetition accuracy | ≤±0.01mm |
| Min. letter | Chinese: 2.0*2.0mm; English: 1.0*1.0mm |
| Working voltage | 110V/220V, 50Hz~60Hz |
| Working condition | Temperature: 0-45℃, humidity: 5%-95% (No condensation) |
| File formats | *.plt, *.dst, *.dxf, *.bmp, *.dwg, *.ai, *.las, support AutoCAD, CoreDraw software |
Plywood Acrylic MDF Laser Cutting Machine 150w Applicable Materials:
Materials can be engraved:
acrylic, wood, cloth, leather, MDF, bamboo, rubber, glass, crystal, granite, marble, tile, ceramic, paper, magic bean, painted metal, etc.
Materials can be cut:
acrylic, wood, cloth, leather, MDF, plywood, bamboo, rubber, asbestos rubber, paper, PVC, foam, EVA, plastic, etc.
Plywood Acrylic MDF Laser Cutting Machine Optional parts:
Plywood Acrylic MDF Laser Cutting Machine Samples
After-Sales Service:
* Training how to install the machine, training how to use the machine.
* Engineers available to service machinery overseas.
* 24/7 on-line receiving your question or requesting.
* Providing solution within 12 hours.
2-YEAR WARRANTY, LIFETIME MAINTENANCE
1.Two-year warranty for the machine, except for consumables.
2.Laser tube warranty:
- CO2 40W, 50W, 60W tubes: 3 months;
- CO2 80W tube: 8 months;
- CO2 100W, 130W, 150W, 180W tubes: 10 months;
- CO2 280W, 300W tubes: 12 months.
3.Optical lens and mirrors are not within warranty scope.
