WS-A1530
1500x3000mm
9.0kw HSD
Japan Servo
Syntec
Vacuum +T-slot
Artcam,JDpaint,Ucancam
Product Description
WS-A1530 Cabinets Doors Woodworking 1530 ATC CNC Router
WS-A1530 Cabinets Doors Woodworking 1530 ATC CNC Router Applications:
Wisdom Woodworking CNC Router,enjoying a high reputation in the market, is popular with many customers from different countries.
Linear ATC CNC Router with Auto Tool Changer is mainly used in furniture making industry, furniture decoration industry, wood craft industry, wood decoration industry, automotive tooling industry, solid wood furniture, classical furniture, decoration material, door cabinets, wooden kitchen furniture, wood materials and other materials processing such as Aluminum, Acrylic, MDF, PVC.
WS-A1530 Cabinets Doors Woodworking 1530 ATC CNC Router Features:
1. Adopt Japan Yaskawa servo motor and drive, built-in encoder, it can stop automatically when errors happened to avoid accidents.
2. Z axis adopt Taiwan TBI ball screw, X/Y/Z axis adopt Taiwan Hiwin guide rail, dual-row, four line ball slider, heavy loading and steady processing.
3. Taiwan Syntec control system can give full function to spindle motor to achieve straight line and perfect curving lines. You can also choose Mach3 control system, Nc studio control system or ShanLong control system depend on budgets.
4. Italy 9KW HSD air cooling spindle with tool changing, high power, original cutters, high precision and long lifetime.
5. 8 pcs linear auto tool changer follow with spindle, it can catch 8pcs different CNC bits for different work, no need to change bits by hand, the tool changing speed just 5s.
6. Strong vacuum work table match with 7.5KW vacuum pump, big suction to fix materials.
WS-A1530 Cabinets Doors Woodworking 1530 ATC CNC Router Technical specification:
Model | WS-A1530 | WS-A2030 |
Working area | 1500x3000mm or 2000x3000mm | |
Spindle power | 9.0kw HSD | 9.0kw HSD |
Spindle speed | 18000~24000rpm/min | |
Inverter | 11.0kw Delta | 11.0kw Delta |
Driving system | Japan Servo motor and drivers | |
Transmission | Taiwan Hiwin Square linear guide rails with X Y axis TBI Ball screw with Z axis | |
Operation system | Syntec control system | |
Dust collector | 3.0kw with double bags | |
Oil lubrication | Automatic | |
Software compatibility | Artcam,Ucancam,JDpaint,etc | |
Working platform | Vacuum fixing | |
Gantry | Wholly cast steel | |
Lathe bed | Thicken steel tube | |
Electronic parts | Schneider | |
Relocating accuracy | ±0.05 mm | |
Max Moving speed | 25000mm/min | |
Max Working speed | 15000mm/min | |
Working voltage | 380v 220v/ 50/60HZ | |
Optional parts:
Rotary attachment
ATC (auto tools changer)
Oil mist sprayer system
Water groove table
Germany Becker pump
WS-A1530 Cabinets Doors Woodworking 1530 ATC CNC Router Samples
After-Sales Service
1. Two years quality guaranty,the machine with parts shall be changed free of charge when if any problem during the warranty period (excluding the consumables).
2. Wholfe Life time maintenance free of charge.
3. Free training course at our plant.
4. 24 hours on line service each day,free technical support.
5. Machine has been installed and tested well before shipping.
6. Provide technical service to the door.
Company Information
Company introduction:
Jinan Wisdom CNC Equipment Co., Ltd is one of the premium and quality-focused manufacturer and supplier in China integrating manufacture, research, marketing and service. We design, develop and manufacture CNC router machine (CNC wood router, stone engraving machine, metal engraving machine, 3 axis CNC router, 4 axis CNC router, 5 axis CNC router, 3D CNC router, CNC milling machine), CNC wood turning lathe, CO2 laser engraving and cutting machine, laser marking machine, fiber laser cutting machine, plasma cutting machine, etc.
Quality makes the core of our organization's philosophy, we are committed to providing customers with high quality products, competitive prices, excellent services and customized solutions. For decade of years development, our products have good market in more than 70 countries and regions including Europe, Africa, Mid east, America, Oceania and Southeast Asia, etc. Besides, we have 24hr customer service hot line, regularly consult customers' needs and suggestions to further improve our products and service.
We make use of the rich Internet information, integrate global market resource, and create a unique marketing and brand promoting mode belonging to "Wisdom". We insists on customer-oriented and non-stopping innovating to achieve common benefits, we whole-heartedly supply products with competitive price and perfect solutions to all users in all kinds of industries.
Packing and Delivery
Packaging and delivery:
Rather careful and professional packing way for machine protection.
1. Film. Put PE film on the machine and some spare parts, then put bubble wrap to the machine.
2. Free-fumigation wooden case with steel tube support on wooden cover. Humidity-proof paper above the wooden plate.
This kind of package could protect the machine very well from dust and humidity etc.
FAQ
FAQ:
A. This is our first cooperation with you, are you believable?
First we are legal China company, with complete formalities.
Second we have been in cnc business industry for 8 years, with long term cooperated agent and end client, and we work for exporting for 8 years, we deal all based on machine quality and honest service.
Third, we can deal from alibaba assurance which can make sure your quality and delivery, we accept all the supervision from the third party.
B. how to select the cnc router machine for our first time?
We will select suitable machine according to your detailed work, better show me your sample picture.Then please tell me the machine size you want, we can customed for you.
Last about the configuration we will make decision according to your work and budget.
C. How to deal with you?
We will make a PI according to our negociate with you about the machine details.
Then you can arrange prepayment for us, after we receive prepayment, we will arrange the manufacture, when machine done, we will take pictures and videos for you, if you satisfy please arrange the balanced payment, then i will arrange ship for you.
D. What's the warranty?
We will provide full 24 months warranty, and whole life time free service. Video call, online support, email communications, Teamviewer support are available.
E. how to learning machine?
We will provide operation manual and working video to guide you how to use it. Our engineer always support as well.
F. How to choose cnc router machine?
1. please tell us your processing material type?tell us your processing material type.
---For wood,acrylic,plywood,mdf,etc nonmetal materials engraving and cutting, choose standard cnc router with vacuum bed or T-slot bed
---for aluminum soft metal or stone marble materials engraving and cutting, cnc router with water groove table optional.
---please tell us your material size?
We have standard size 600x900mm,1200x1200mm,1300x2500mm, 1500x3000mm, 2000x3000mm, 2000x4000mm,etc.Other size can be done as customized.
G.How do you send your CNC router machine?
They are firstly greased thoroughly and packaged in a free-fumigation wooden crate.
Usually, we send machine by ship, sometimes, as customer’s requirement, send by air or by train.
When the goods arrive at your sea port or destination, you can pick up goods with the bill of lading we offered.
Or we can arrange the cargo agent to send goods to your door.
H.Does machine comes with software?
Yes, we offer intelligent and compatible software with machine, so it will be more convenient for you to operate machine.
I. Do you offer training about products?
Yes, customer could get free training at our factory; or we can assign technician arrive at customer’s company for the training at some charge, and accommodation, food, tickets will be charged.
