Views: 229 Author: Sophia Jia Publish Time: 2019-07-06 Origin: Site
The wood board and plexiglass laser cutting machine has a wide processing range and a large working range. The user-friendly automatic lifting work platform design makes the equipment meet the processing of various width materials and at the same time make the materials of different thicknesses ensure the best. Focus and processing effects. It can also cooperate with the rotating device to carry out fine carving of various non-metallic cylindrical materials such as bamboo and wood.
Scope of application:
It is suitable for non-metallic materials such as double-color plates, organic glass and plates.
technical parameter:
Working platform Zinc iron honeycomb working platform
Worktable electric lifting range 0-150mm
Maximum speed of idle travel 0-24000mm/min
Repeat positioning accuracy ±0.1mm
Motion system Offline step control system
Cooling system forced water cooling circulation system
Power supply AC220V±5% / 50HZ
Support graphics formats AI, BMP, PLT, DXF, DST, etc.
Standard 550W up and down smoking machine, micro air compressor
Optional glass tube sealed off CO2 laser
Automatic counter-rotating engraving device, automatic control of high-pressure blowing valve,
Constant temperature chiller, strip working platform
